Omron S8FS-C05048D Power supply 50W, 100-240 VAC input, 48VDC, 1.1A output Din Rail
Availability: Out of stock
₹ 0.0 (+18.0% GST extra)
(Min.Order)
Omron S8FS-C05048D Power Supply Din Rail,Covered type,100 to 240 VAC, Power rating 50W, Output: 48VDC, 1.1A Terminal block facing forward (Screw terminal), Harmonic current emissions,Omron Smps,Industrial use for switch mode Power Supply Omron
Power rating Item Output voltage |
50 W |
||||||
5 V |
12 V |
15 V |
24 V |
48 V |
|||
Efficiency * |
115 VAC input |
79% typ. |
83% typ. |
84% typ. |
86% typ. |
87% typ. |
|
230 VAC input |
80% typ. |
84% typ. |
85% typ. |
86% typ. |
87% typ. |
||
Input |
Voltage range * |
Single phase 85 to 264 VAC, 120 to 370 VDC (The L terminal for the DC input is the positive side and safety standards do not apply.) (Derating is required according to the input voltage. Refer to Derating Curves on page 18.) |
|||||
Frequency * |
50 /60 Hz (47 to 450 Hz) |
||||||
Current * |
115 VAC input |
0.97 A typ. |
|||||
230 VAC input |
0.59 A typ. |
||||||
Power factor |
--- |
||||||
Leakage current |
115 VAC input |
0.25 mA |
0.25 mA |
0.25 mA |
0.25 mA |
0.25 mA |
|
230 VAC input |
0.60 mA |
0.55 mA |
0.55 mA |
0.55 mA |
0.55 mA |
||
Inrush current * (for a cold start at 25°) |
115 VAC input |
16 A typ. |
|||||
230 VAC input |
32 A typ. |
||||||
Output |
Rated Output Current |
10 A |
4.2 A |
3.4 A |
2.2 A |
1.1 A |
|
Voltage adjustment range * |
-10% to 10% (with V. ADJ) |
||||||
Ripple & Noise voltage * |
100 to 240 VAC input |
80 mVp-p max. |
110 mVp-p max. |
100 mVp-p max. |
100 mVp-p max. |
120 mVp-p max. |
|
Input variation influence * |
0.5% max. |
||||||
Load variation influence * |
1.0% max. |
||||||
Temperature vari- ation influence |
100 to 240 VAC input |
0.03%/°C max. |
|||||
Startup time * |
115 VAC input |
730 ms typ. |
730 ms typ. |
710 ms typ. |
710 ms typ. |
770 ms typ. |
|
230 VAC input |
680 ms typ. |
670 ms typ. |
610 ms typ. |
640 ms typ. |
690 ms typ. |
||
Hold time * |
115 VAC input |
12 ms typ. |
14 ms typ. |
14 ms typ. |
14 ms typ. |
14 ms typ. |
|
230 VAC input |
71 ms typ. |
77 ms typ. |
78 ms typ. |
77 ms typ. |
80 ms typ. |
||
Addi- tional func- tions |
Overload protection |
Yes, automatic reset |
|||||
Overvoltage protection * |
Yes, 115% or higher of rated output voltage, power shut off (shut off the input voltage and turn on the input again) |
||||||
Overheat protection |
No |
||||||
Series operation |
Yes (For up to 2 Power Supplies, external diodes are required.) |
||||||
Parallel operation |
No (However, backup operation is possible, external diodes are required.) |
||||||
Remote sensing |
No |
||||||
Remote control |
No |
||||||
Output indicator |
Yes (LED: Green) |
||||||
Insula- tion |
Withstand voltage |
3 kVAC for 1 min. (between all input terminals and output terminals) current cutoff 20 mA |
|||||
2 kVAC for 1 min. (between all input terminals and PE terminals) current cutoff 20 mA |
|||||||
1 kVAC for 1 min. (between all output terminals and PE terminals) current cutoff 20 mA |
|||||||
Insulation resistance |
100 MÙ min. (between all output terminals and all input terminals/PE terminals) at 500 VDC |
||||||
Envi- ronment |
Ambient operating temperature |
-20 to 60°C (Derating is required according to the temperature. Refer to Derating Curves on page 17.) (with no condensation or icing) |
|||||
Storage temperature |
-40 to 85°C (with no condensation or icing) |
||||||
Ambient operating humidity |
20% to 90% (Storage humidity: 10% to 95%) |
||||||
Vibration resistance |
10 to 55 Hz, 0.375-mm half amplitude for 2 h each in X, Y, and Z directions 10 to 500 Hz, 0.26-mm half amplitude for 1 h each in X, Y, and Z directions |
||||||
Shock resistance |
150 m/s2, 3 times each in ±X, ±Y, ±Z directions |
||||||
Reliabil- ity |
MTBF |
135,000 hrs min. |
|||||
Life expectancy * |
10 years min. |
||||||
Con- struc- tion |
Dimensions (W´H´D) |
Refer to Dimensions on pages 20 and 24. |
|||||
Weight |
300 g max. |
||||||
Cooling fan |
No |
||||||
Degree of protection |
--- |
||||||
Stan- dards |
Harmonic current emissions |
Conforms to EN 61000-3-2, GB17625.1 |
|||||
EMI |
Conducted Emissions |
Conforms to EN 61204-3 Class B, EN 55011 Class B, GB9254 |
|||||
Radiated Emissions |
Conforms to EN 61204-3 Class B, EN 55011 Class B, GB9254 |
||||||
EMS |
Conforms to EN 61204-3 high severity levels |
||||||
Safety Standards |
Approved Standards UL : cURus UL 60950-1 (Recognition) OVC II Pol2 CSA: cURus C22.2 No60950-1 CCC: GB4943 Conformed Standards EN: EN 60950-1 OVC II Pol2 |
||||||
Marine Standards |
No |
||||||
SEMI |
No |
